X4 Montage

On-board 2GB SD card stores up to 200 hours of acquired data

click on the image to enlarge

B-Alert EEG Systems:

Back to Advanced Brain Monitoring Products

Reseach EEG Products :



B-Alert X4 EEG Headset System

Ultra-Portable 4 Channel Wireless EEG Headset

The B-Alert X4 wire headset features a compact form factor to maximize ease-of-use and comfort in real-world environments. The mid-line sites deliver real-time, second-by-second B-Alert Cognitive State Metrics of high and low engagement, confusion/fatigue, and sleep onset. The on-board SD card enables extended recordings for field applications, including sleep deprivation and ergonomic studies. For first-time and experienced EEG users alike, B-Alert X4 is a practical solution for quickly implementing psychophysiological assessment.

Product Features:

• 3 channels of high-quality EEG, plus 1 optional channel for ECG, EMG, or EOG (4 Channels @ 256Hz)
• On-board 2GB SD card for data storage
• Comfortable and non-intrusive; sets up in less than 5 minutes
• Automated wireless impedance checks
• Bluetooth wireless signal transmission up to 10 meters
• 6 hrs rechargeable battery life in wireless mode; 16 hrs in SD card mode
• On-board accelerometer to quantify head movement & position
• Data quality monitoring and feedback
• Multiple options for data synchronization
• Sizing to fit adolescent through adult heads
• SDK fully compatible with MatLab, EEGLab, and BCI2000



The B-Alert X4 System will pair with either B-AlertLive or B-AlertLab.
