B-Alert X24 EEG System

Flexible 24 Channel Wireless EEG Headset

The B-Alert X24 combines power and flexibility for mobile neurophysiological monitoring, offering two interchangeable, pre-configured sensor strips -- each of which assures individualized fit and accurate site placement across subjects. The lightweight headset delivers real-time EEG from the standard 10-20 configuration for use in quantitative analyses, LORETA, BCI, neurofeedback training, single-trial ERPs, and the validated X-Series Cognitive State and Mental Workload Metrics. The included External Syncing Unit (ESU) offers further signal integration flexibility, enabling precise millisecond synchronization across 3rd party systems. From biomarker development to neurorehabilitation applications, B-Alert X24 is the most versatile wireless-EEG system available.

Product Features:

• 20 channels of high-quality EEG, plus 4 optional channel for ECG, EMG, or EOG (24 Channels @ 256Hz)
• Comfortable and non-intrusive; sets up in about 15 minutes
• Automated wireless impedance checks
• Enhanced ESU-MC Bluetooth wireless range up to 20 meters
• 8+ hour rechargeable battery life
• On-board accelerometer to quantify head movement & position
• Data quality monitoring and feedback
• Multiple options for data synchronization
• Sizing to fit adolescent through adult heads
• SDK fully compatible with MatLab, EEGLab, BCI2000, qEEG, and many neurofeedback packages





Standard 10-20 Montage

Visual Montage

The ESU features serial + parallel ports for precision syncing and is included with every B-Alert X24

click on the image to enlarge

The B-Alert X4 System will pair with either B-AlertLive or B-AlertLab.
